Fully Automatic Capsule Filling Machine
Advanced and efficient hard gelatin capsule filling, Senieer fully automatic capsule filling machine enhances your capsule filling speed and efficiency!
Introduction of Fully Automatic Capsule Filling Machine
Senieer’s fully automatic capsule filling machine is a cutting-edge capsule filling equipment that is suitable for filling powders, granules or small pellets into hard gelatin. It is designed to enhance the filling and production efficiency of factories. After incorporating advanced pharmaceutical technology from the frontier, Senieer’s fully automatic capsule filling machine stands out from its diverse capsule filling machine series, which is suitable for factories and companies who are from diverse industries like pharmaceutical, food and chemicals. It is equipped with new electronic devices and loading and filling systems to boost the production efficiency. The unique dividing system enables it to be compatible with almost any capsule types like hard or soft gelatin capsules. The monitoring system is very smart and just need one operator can finish this work.
Different Types of Fully Automatic Capsule Filling Machines
Senieer offers different types of fully automatic capsule filling machines according to your needs. From small-scale, medium-scale, to large-yielding type, we provides the most suitable model for you.
Find Fully Automatic Capsule Filling Machine According To Your Industry Or Process
Senieer offers different types of capsule filling machines to meet clients’ needs and expectations. From fully automatic to semi-auto capsule filling machines, each type is suitable for different production applications. The fully automatic capsule filling machine is tailored to those who need a large scale of production requirement.
The fully automatic capsule filling machine achieves the fully automation of loading, filling and sealing, and it involves many processes in it such as capsule broadcasting( align and distribute empty capsules), capsule separating(separate the capsule body and cap), metering and filling, waste rejecting, etc.
Guidelines For Fully Automatic Capsule Filling Machine
Senieer has many models of fully automatic capsule filling machines and each type is tailored to meet different needs and requirements of clients. Full enclosed design, no dust accumulation. No dust capsule feeding device, purification compressed air, remove dust inside the mold cavity. The production capacity range from tens of thousands to hundreds of thousands to meet various production scale.
Working Process of Fully Automatic Capsule Filling Machine
Capsules Sorting And Orientation
First, setting up the machine. The disordered empty capsules in the hopper will be aligned and distributed evenly by laser sensors or mechanical brushes.
Capsule Separation
Separating the body and cap of capsules utilizing vacuum system or mechanical needle system. Which separating system is chosen is determined by the material properties. For granules or pellets, vacuum separating system is a good choice. But it is sensitive to the static electricity or stickness of powders. So, for powders, mechanical needle system is a better choice.
Capsule Filling
In the filling station, materials such as powders, granules or pellets are filled into the empty hard gelatin capsules.
Capsule Caps Replacement And Sealing
By press plate or rotating lock devices to place the capsule caps onto the filled capsules again and have a sealing, ensuring the safety and hygiene of filling materials.
Discharging And Rejection
The filled capsules will be discharged for the subsequent processes. The qualified capsules will experience the processes of sorting, inspection, cleaning, polishing and packaging, and the unqualified capsules will be rejected.
Benefits of Fully Automatic Capsule Filling Machine
- Suitable for various capsule sizes including 000#, 00#, 0#, 1#, 2#, 3#, 4#, 5#.
- Compliant with international quality standard such as cGMP.
- Enclosed environment of filling and dosing, no dust out of the devices.
- Fully automatic vacuum loading materials and capsules.
- The control system can be operated in touch screen interface.
- Smart remote control system, all operation
- Equipped with automatic stop system of gate control and alarm.
- New enclosed containment of turret.
- Fully automatic operation to reduce manual costs and increase productivity.
- Imported precision indexer with stable operation, high precision indexing, compact structure and low noise.
- Highest-yielding equipment so far in Globe(America, UK, Brazil, Egypt, Malaysia, Arabia.)
Superior And Professional After-Sales Service
- Comprehensive instruction and maintenance– Senieer offers lifetime after-sales services including installation&commissioning, training, maintenance, regular contact to learn about the operating conditions of equipment.
- Use instruction– we will offer onsite and video instructions to show you how to operate and use equipment. The installation&commissioning and training time ranges from 1 day to 3 months determined by the equipment numbers and complexity of onsite installation.
If you have any questions about the use of machines, welcome to contact us at any time. At the warranty period, if happens any malfunction, we will dispatch professional technicians to repair and maintain it.
Why Choose Senieer Fully Automatic Capsule Filling Machine?
Senieer fully automatic capsule filling machine achieves the fully automation of equipment operation. It means that the operator needs very little operation( monitoring and necessary instructions during the operating of equipment.
It has two materials feeding functions: timed and qualified feeding, capacitive sensing feeding, which ensures that the materials are filled accurately and precisely. The monitoring process is simple for operators because it is fully automated and the alarm system will warn you when the quantity of feeding materials is low or high.
