Senieer SBU150 medium speed bottle unscrambler offers high-accurate and automatic bottle unscrambling functions. Easy to operate, dust-proof, low noise, automatic upside-down and inverted bottle detection and rejection features to meet your diverse needs and requirements. Customized service is also available to satisfy your more demands.
Senieer SBU150 medium speed bottle unscrambler is an automatic bottle unscrambler used for sorting and orienting randomly fed bottles into a uniform position(usually upright) for the subsequent filling, capping, sealing and labeling. It is suitable for a wide range of bottle sizes and shapes. The speed of SBU150 is medium, which is suitable for medium-scale production needs. This bottle unscrambler can deal with bottles with various materials such as PET plastic bottle. The function of automatic detection and rejection of upside down or inverted bottles enables high efficient production, which makes the pass rate of bottle unscrambling reaches 100%.
No. | Items | Details |
1 | Max output | 150 b/pm (measuring D:45mm；H:80mm) |
2 | Bottle specification | 15~500ml |
3 | Voltage/Frequency | AC220V/50Hz |
4 | Power | 0.50Kw |
5 | Pressure | 0.30Pa |
6 | Dimension(L×W×H) | 1100×1580×1210 |
7 | Weight | 337Kg |
Details Of SBU150 Medium Speed Bottle Unscrambler
Senieer SBU150 medium speed bottle unscrambler is suitable for multiple sizes of bottles from 15~500ml, such as Mineral water bottles, beverage bottles, medicine bottles, cosmetic bottles， etc. Its max speed of bottle unscrambling is 150b/pm. For food &beverage industry, it is a medium production speed, but is high production speed for cosmetics industry. This machine is mainly used in the unscrambling of simple bottle shape(cylindrical mineral water bottle) and lightweight PET bottles. For Irregular-shaped bottles(square sauce bottle, cosmetic bottle with handle) and glass or heavy bottles, the speed of SBU150 is a little high and need to adopt special measurements.
Key Parts Of SBU150 Medium Speed Bottle Unscrambler
SBU150 Medium Speed Bottle Unscrambler is a rotary type and its key components include:
Infeed hopper
Bulk of disordered bottles are poured into it and then into turn table for further unscrambling.
Orientation system
The infeed disordered bottles will be sorted and oriented by orienting system into a correct position(upright).
Discharge conveyor
After unscrambling the bulk bottles into correction position, these bottles will be transferred into next stage for further processing such as filling, capping, sealing and labeling.
Why Choose Senieer SBU150 Medium Speed Bottle Unscrambler?
Senieer is one-stop turnkey projects solutions supplier. As one of the best bottle unscrambler manufacturers in globe, Senieer offers high-quality, cost effective, hygienic and GMP-compliant bottle unscramblers. We can also custom design and adjust some parameters according to your specific requirements.
Senieer SBU150 medium speed bottle unscrambler is suitable for the sorting and orienting of PET plastic bottles or glass bottles. According to the differences of bottle shapes and materials, rotary disc or vibratory guide is available. It adopts PLC touch control system to enable easy, simple and smart operation of machine.
